Kavvia DermaLux Diode Laser
Kavvia DermaLux Diode Laser
Kavvia DermaLux Diode Laser
Kavvia DermaLux Diode Laser
Kavvia DermaLux Diode Laser
Kavvia DermaLux Diode Laser
Kavvia DermaLux Diode Laser
Kavvia DermaLux Diode Laser
Kavvia DermaLux Diode Laser
Kavvia DermaLux Diode Laser

Kavvia DermaLux Diode Laser

by Kavvia
Save 21% Save 21%
$31,590.00
$31,590.00 - $31,590.00
$31,590.00
$24,999.00
$24,999.00 - $24,999.00
$24,999.00

✓ Authorized Kavvia Dealer
✓ Lowest Price Guaranteed
✓ FREE & FAST Shipping: In Stock and Ready to Ship
✓ Questions? Call an RFA Team Member: 1-855-864-6442

KAVVIA

Kavvia DermaLux Diode Laser

The Kavvia DermaLux Diode Laser is a professional laser hair removal system that works at 808 nm, with 755 nm and 1064 nm available as options on the same platform. Energy density is set anywhere from 0 to 300 J/cm2. Pulse width runs from 10 to 400 ms, the repetition rate from 1 to 10 Hz, and the duty cycle is 33%. The HS-DI-1800 handpiece takes three spot sizes, 12x32, 12x25 and 12x15 mm. Cooling is a conducted cooled stack with FAC technology, and the machine comes with a one-year warranty.

Energy density, pulse width and repetition rate are three separate settings at the console, and each one can be recorded and repeated at the next appointment. The optics are a micro optical design that forms the focusing spot in place of an optical waveguide. Spot size is decided by which of the three windows is fitted, and the 12x32 mm window covers more ground per placement than the 12x15 mm one. Treatments cover full body and targeted hair removal, underarm, bikini and Brazilian work, facial hair reduction and men's grooming, all of it from a console built for aesthetic clinics.

Wavelength
808 nm
755 nm and 1064 nm optional
Energy Density
0 to 300 J/cm2
set at the console
Spot Size
12x32 mm
12x25 and 12x15 mm also fitted
Pulse Width
10 to 400 ms
1 to 10 Hz repetition
HS-DI-1800 handpiece Conducted cooled stack 33% duty cycle Micro optical spot
Kavvia DermaLux Diode Laser, the console and handpiece

SYSTEM

Three wavelengths on one platform

The DermaLux runs 808 nm as its working line, with 755 nm and 1064 nm available on the same console. Energy density, pulse width and repetition rate move independently of each other, and the handpiece is built without an optical waveguide.

Three diode lines on one console
808 nm is the working line, with 755 nm and 1064 nm available as options. One console covers three diode wavelengths rather than three machines.
755 / 808 / 1064 nm
Energy density across the full span
Energy density is set anywhere from 0 to 300 J/cm2 at the console, so a light pass on fine hair and a heavier one on coarse hair run on the same machine.
0 to 300 J/cm2
Pulse width and rate move apart
Pulse width runs from 10 to 400 ms and the repetition rate from 1 to 10 Hz, at a 33% duty cycle. Both are set at the console.
10 to 400 ms
The optics replace the waveguide
A micro optical design forms the focusing spot in place of an optical waveguide structure. The handpiece that results is smaller and lighter than a waveguide handle.
Micro optical spot

TREATMENTS

What it is used for

Hair removal is the whole of the treatment list, and it is split five ways by the area being worked. Spot size, energy density and pulse width are what a clinic changes between them.

Full body hair removal
BODY
Targeted area hair removal
BODY
Underarm hair removal
BODY
Bikini and Brazilian
BODY
Facial hair reduction
FACE
Men's grooming
FACE AND BODY
Spot up to 12x32 mm
COVERAGE
Energy density to 300 J/cm2
CONTROL

RANGE

The Kavvia laser range

Six lasers make up the Kavvia range, separated by the light source each one uses. The DermaLux is one of the two diode machines in it.

Kavvia Resurf CO2 Fractional Laser, fractional CO2 console
Kavvia Resurf CO2 Fractional Laser
Fractional CO2 at 10600 nm, the ablative laser in the range.
10600 nm 50 W Four modes
Shop the Resurf CO2
Kavvia Dualis X ND:YAG Laser, ND:YAG console
Kavvia Dualis X ND:YAG Laser
An ND:YAG platform for pigment and tattoo work.
ND:YAG 1064 and 532 nm
Shop the Dualis X
Kavvia PicoPulse Picosecond Laser, picosecond console
Kavvia PicoPulse Picosecond Laser
Pulses measured in picoseconds, not nanoseconds.
Picosecond 450 ps
Shop the PicoPulse
Currently viewing
Kavvia DermaLux Diode Laser, diode console
Kavvia DermaLux Diode Laser
A diode platform, the first of two in the range.
Diode 808 nm
Currently viewing
Kavvia Luma 808 Diode Laser, 808 nm diode console
Kavvia Luma 808 Diode Laser
The second diode platform, running at 808 nm.
808 nm diode
Shop the Luma 808
Kavvia AuraLight IPL Laser, IPL console
Kavvia AuraLight IPL Laser
Intense pulsed light, a broad-spectrum source.
IPL 1 to 10 Hz
Shop the AuraLight

FAQ

Frequently asked questions

808 nm is the working line. 755 nm and 1064 nm are available as options on the same platform, so one console can carry more than one diode wavelength.
Hair removal, across five areas: full body and targeted work, underarm, bikini and Brazilian, facial hair reduction and men's grooming. It is a clinic console built for aesthetic professionals.
Anywhere from 0 to 300 J/cm2, set at the console. Pulse width is a separate setting, from 10 to 400 ms.
From 1 to 10 Hz, at a 33% duty cycle. The rate and the pulse width are set independently of each other.
Three, on the HS-DI-1800 handle: 12x32 mm, 12x25 mm and 12x15 mm. The 12x32 mm window covers the most ground in a single placement.
A conducted cooled stack with FAC technology. Heat dissipation is handled in the packaging around the laser bar.
The waveguide structure is replaced by a micro optical design that forms the focusing spot. The handpiece is smaller and lighter than a waveguide handle, and it is what the operator holds through a full body pass.
The laser bar is life tested past 50 million shots, and the machine comes with a one-year warranty.
It is the share of the time the laser is actually emitting while it is firing at a set rate. On the DermaLux that share is 33%.
The DermaLux is the platform that carries 755 nm and 1064 nm as options alongside its 808 nm working line, and its energy density, pulse width and repetition rate are all operator-set. The treatment list is the same on both machines.
  • Wavelength: 755nm, 808nm, 1064nm optional
  • Energy density: 0-300 J/cm2
  • Pulse width: 10-400 ms
  • Spot size: 12x32 / 12x25 / 12x15 mm
  • Frequency: 1-10 Hz
  • Duty cycle: 33%
  • Handle model: HS-DI-1800
  • Cooling: conducted cooled stack with FAC technology
  • Wavelength options: 755nm, 808nm and 1064nm optional on one platform
  • Spot sizes: 12x32, 12x25 and 12x15 mm at the handle
  • Energy density: set from 0 to 300 J/cm2
  • Pulse width: 10 to 400 ms
  • Repetition rate: 1 to 10 Hz
  • Optical design: micro optical focusing spot in place of an optical waveguide
  • Treatments: full body and targeted hair removal, underarm, bikini and Brazilian, facial hair reduction and men's grooming
